Rotary-Vane Vacuum Pump, Two-Stage

Rotary-Vane Vacuum Pump, Two-Stage, 1003317 [U34000], Vacuum Pumps
Rotary-Vane Vacuum Pump, Two-Stage, 1003317 [U34000], Vacuum Pumps
In Stock
In stock

Application: ..
This rotary-vane vacuum pump is used for the evacuation of recipients during the conduct of vacuum experiments in school education up to internships at universities. It is not intended for industrial use.

Product Information: ..
High performance, compact, two-stage, oil-sealed rotary vane pump for vacuum experiments. With thermal overload protection, handle, air valve, manometer and hose nipple.
Includes pump oil.

Specifications: ..
Power supply: 115 V ±10%, 60 Hz
  230 V ±10%, 50/60 Hz
Suction capacity: 100 l/min
Final pressure: 0,003 hPa
Motor power: 245 W
Oil capacity: 350 ml
Manometer: 0 – 1000 mbar
Hose nipple: 10 mm Ø
Dimensions: 335 mm x 138 mm x 250 mm approx.
Weight: 11 kg approx.
Ambient temperature: 5°C – 40°C approx.
Storage temperature: -20°C – 70°C
Relative humidity: < 85%, with no condensation
Degree of pollution: 2
Protection type: IP20
Fuse: 20 A, fast


Item No.: 1003317 [U34000]
Weight 13.004 kg

Documentation

PDF Product Manual - Rotary-Vane Vacuum Pump, Two-Stage - U34000 [1003317] (EN)
