Parallel-Plate Capacitor,
Type D
![Parallel-Plate Capacitor,
Type D, 1006798 [U8492355], Electrostatics](/imagelibrary/U8492355/U8492355_01_Parallel-Plate-Capacitor-Type-D.jpg)
![Parallel-Plate Capacitor,
Type D, 1006798 [U8492355], Electrostatics](/thumblibrary/U8492355/U8492355_01_1200_1200_Parallel-Plate-Capacitor-Type-D.jpg)
Parallel-Plate Capacitor,
Type D
| Product Information: .. |
| This parallel-plate capacitor is used: .. .. | |
| • | to investigate the relationship between electric charge and voltage. .. |
| • | to quantify capacitance as a function of plate spacing |
| • | to measure the dielectric constant ε |
| • | to precisely determine the vacuum permittivity ε0 .. |
The plate spacing can be finely adjusted and read off from a display to an accuracy of 1/10 mm. Plates can be adjusted between 0 mm and 20 mm via a spindle.
| Specifications: .. |
| Plates: | solid casting |
| Plate spacing: | 0 – 160 mm |
| Plate area: | 500 cm² |
| Weight: | 4.2 kg approx. |
Item No.: 1006798 [U8492355]
| Weight | 4.289 kg |
| Brand | 3B Scientific |
